Some examples

Send-driven (client/server)

Filesystems, serial ports, consoles, and sound cards all use the client/server model. A C language application program takes on the role of the client and sends requests to these servers. The servers perform whatever work was specified, and reply with the answer.

Some of these traditional “client/server” servers may in fact actually be reply-driven (server/subserver) servers! This is because, to the ultimate client, they appear as a standard server, even though the server itself uses server/subserver methods to get the work done. What I mean by that is, the client still sends a message to what it thinks is the “service providing process.” What actually happens is that the “service providing process” simply delegates the client's work to a different process (the subserver).

Reply-driven (server/subserver)

One of the more popular reply-driven programs is a fractal graphics program distributed over the network. The master program divides the screen into several areas, for example, 64 regions. At startup, the master program is given a list of nodes that can participate in this activity. The master program starts up worker (subserver) programs, one on each of the nodes, and then waits for the worker programs to send to the master.

The master then repeatedly picks “unfilled” regions (of the 64 on screen) and delegates the fractal computation work to the worker program on another node by replying to it. When the worker program has completed the calculations, it sends the results back to the master, which displays the result on the screen.

Because the worker program sent to the master, it's now up to the master to again reply with more work. The master continues doing this until all 64 areas on the screen have been filled.

An important subtlety

Because the master program is delegating work to worker programs, the master program can't afford to become blocked on any one program! In a traditional send-driven approach, you'd expect the master to create a program and then send to it. Unfortunately, the master program wouldn't be replied to until the worker program was done, meaning that the master program couldn't send simultaneously to another worker program, effectively negating the advantages of having multiple worker nodes.

Figure 1. One master, multiple workers.

The solution to this problem is to have the worker programs start up, and ask the master program if there's any work to do by sending it a message. Once again, we've used the direction of the arrows in the diagram to indicate the direction of the send. Now the worker programs are waiting for the master to reply. When something tells the master program to do some work, it replies to one or more of the workers, which causes them to go off and do the work. This lets the workers go about their business; the master program can still respond to new requests (it's not blocked waiting for a reply from one of the workers).

Multithreaded server

Multithreaded servers are indistinguishable from single-threaded servers from the client's point of view. In fact, the designer of a server can just “turn on” multithreading by starting another thread.

In any event, the server can still make use of multiple CPUs in an SMP configuration, even if it is servicing only one “client.” What does that mean? Let's revisit the fractal graphics example. When a subserver gets a request from the server to “compute,” there's absolutely nothing stopping the subserver from starting up multiple threads on multiple CPUs to service the one request. In fact, to make the application scale better across networks that have some SMP boxes and some single-CPU boxes, the server and subserver can initially exchange a message whereby the subserver tells the server how many CPUs it has—this lets it know how many requests it can service simultaneously. The server would then queue up more requests for SMP boxes, allowing the SMP boxes to do more work than single-CPU boxes.
